Supports the battery mode or non-battery mode 2. Surge and reverse connection protections to support the lithium battery system perfectly 3. Three charging modes: Solar only, Solar priority, Utility & Solar 4. Two AC output modes: Utility priority and Inverter priority 5. High tracking efficiency of MPPT no less than 99.5% 6. PFC technology achieves a high power factor of AC to DC charging and reduces grid capacity usage 7. Advanced SPWM technology and pure sine wave output 8. Customized charging current and discharging limited current 9. SOC with the self-learning feature is visible on LCD 10. 4.2 inch LCD to monitor and modify system parameters 11. Optional WiFi or GPRS Remote control by the RS485 isolated communication port 12. Optional BMS-Link port, which takes the charging and discharging control from BMS
|
Model |
MP3043-1020P65 |
MP5043-1020P65 |
|
Rated battery voltage |
48VDC |
|
|
Battery work voltage range |
42.4VDC to 64.0VDC |
|
|
Battery type |
Lithium battery/lead-acid battery |
|
|
Inverter output |
||
|
Continuous output power(@25℃/4H) |
3000W |
5000W |
|
5S Continuous output power (@25℃) |
6000W |
10000W |
|
Rated output voltage |
220VAC/230VAC/240VAC±5%; 110VAC/115VAC/120VAC±5% |
|
|
Rated output frequency |
50Hz/60Hz±0.5Hz |
|
|
Output wave |
Pure Sine Wave |
|
|
Load power factor |
0.2－1(VA ≤ continuous output power) |
|
|
Distortion THD |
≤ 5% (Resistive load) |
|
|
Max. inverter efficiency |
＞93.6% |
|
|
Full load efficiency |
＞90% |
|
|
Utility transfer time |
≤10mS |
≤10mS |
|
Inverter to bypass transfer time |
≤1mS |
≤1mS |
|
Utility input |
||
|
Utility work voltage range |
170VAC to 285VAC |
|
|
Utility input frequency range |
40Hz to 70Hz |
|
|
Rated Utility input power |
4500W(@240VAC) |
7500W(@240VAC) |
|
(Charging plus Bypass) |
||
|
Utility charging power factor |
About 1 |
|
|
Max. Utility charging current |
50A |
80A |
|
Solar charging |
||
|
Max. PV open circuit voltage |
195V (At minimum operating environment temperature) |
|
|
MPPT working voltage |
(Battery voltage plus 10V) to 145V |
|
|
Max. PV charging power |
5000W (1700W/way) |
|
|
Max. PV charging current |
100A (34A/way) |
|
|
MPPT tracking efficiency |
≥99.5% |
|
|
Charging conversion efficiency |
＞95% |
|
|
Temperature compensate coefficient |
-3mV/℃/2V (Default) |
|
|
Inverter/charger charging current |
||
|
Max. inverter/charger charging current |
Default 100A (Settable, range 0－100A) |
|
|
Others |
||
|
No-load consumption |
≤ 48V/ 0.7A |
|
|
Model |
MP3043-1020P65 |
MP5043-1020P65 |
|
Static consumption |
≤ 48V/ 0.15A |
|
|
Enclosure |
IP65 |
|
|
Relative humidity |
< 95% (N.C.) |
|
|
Altitude |
4000m (If the altitude exceeds 2000 meters, the actual output power is reduced appropriately) |
|
|
Work temperature |
-20℃ to 55℃ (When the environment temperature exceeds 25℃, the actual output power is reduced appropriately) |
|
|
Storage temperature |
-40℃ to 60℃ |
|
|
Mechanical parameters |
||
|
Dimension (Length x Width x Height) |
848mm×435mm×249mm |
935mm×475mm×255mm |
|
Mounting size (Length x Width) |
260mmx160mm |
260mmx160mm |
|
Mounting hole size |
Ф10mm |
Ф10mm |
|
Net Weight |
52.0kg |
66.0kg |
